Description

• Hytera’s Latest Body Worn Camera UK model
• 1080p at 30FPS
• 32 – 128GB Storage
• 121° Angle Lens
• 2” Colour Display
• Streaming Capable
• PTT Functionality
• Built-In Back-up Battery
• AES256 Encryption
• Range of Integrated Software Solutions
• Sim Card Slot
• Infra-Red Nightvision with 10m Range
• Robust & Durable Construction
• IP68 Rating
• Includes charger, USB cable & belt clip


  Hytera’s Latest Body Worn Camera UK Model
  The Hytera VM580D Body Worn Camera is the first on Hytera’s new generation of wireless body cameras. Replacing the VM550 & VM550D, the Hytera VM580D is thinner than its predecessors with a built in sim card slot for video streaming and push to talk functionality. It is capable of operating over LTE networks and offers 1080p at 30fps video recording. WHile not the best body camera UK model for high resolution, 1080p at 30FPS is pretty standard.


  AES256 Encryption
  The Hytera VM580D Body Worn Camera utilises AES256 encryption in order to remain GDPR compliant. Decryption is handled by one of the several software solutions available for the VM580D which are sold separately. For more information about this, please call us on 01722 444 806.


  Streaming Capable
  The Hytera VM580D Body Worn Camera has a built-in sim card slot for use with mobile data. It can utilise wireless LTE networks to stream video to a control room or server location depending on your software and support infrastructure


  PTT Functionality
  The Hytera VM580D can act as a substitute for a separate radio due to its Press-to-Talk functionality. When used in conjunction with its software ecosystem, the Hytera VM580D can stream audio to a central control room just like a radio.


  Infrared Nightvision with a 10m Range
  The Hytera VM580D has a built in Infrared lamp that allows footage to be taken in dark environments with up to 10m visibility. When the infrared kicks in, the footage is recorded in grey scale.


  Built-In Back-Up Battery
  The Hytera VM580D has a built-in back-up battery that allows the camera to keep function for between 3 – 5 minutes after the primary battery has been damaged or removed. This allows for the seamless transfer of spare batteries during extended shifts without interfering with recording even if done continuously.


  Robust and Rugged Design
  The Hytera VM580D Body Worn Camera has an IP68 rating and has been drop tested to 2m according to the MIL MIL-810G 2 standard which is more than most commonly available body camera models.


  What’s in the Box
  The Hytera VM580D Body Worn Camera ships with one wireless body camera, one charger, a USB cable and belt clip in the package.


  Made in China
  The Hytera VM580D was made by Hytera, one of the world’s leading radio communication companies that have offices in dozens of countries around the world. The vast majority of their products are made in China.



  Dimensions (H x W x D)	94 x 63 x 20mm
  Weight	172g (including battery and belt clip)
  Storage Capacity	32GB, 64GB, and 128GB
  Main Chip	MTK6739
  Operating System	Android 7.1
  Image Sensor	CMOS OV4689
  Ram	2GB
  Rom	16GB
  Sim Type	Nano-Sim
  Field of View	121°
  Focus Range	0.5m
  Battery Life (Continuous Video Recording)	≥ 8 hours (720p@30 fps
  Battery Capacity	3000 mAh
  Charging Time	≤ 4 hours
  Screen Type	TFT LCD colourful touch screen
  Screen Size	2.0inch
  Screen Resolution	320 x 240 QVGA
  Video Format and Resolutions	1080p@30 fps, 720p@30 fps, 480p@30 fps
  Image Format and Resolutions	16 MP, 5 MP, 3 MP
  Pre-recording/Post-recording	30 Seconds
  Encryption	AES256
  WLAN	802.11 b/g/n
  BT	BT 4.2
  USB Type	Micro USB
  Night Vision Range	Upto 10 Metres
  White LED	Supported
  Ingress Protection	IP68
  Drop Resistance	2 meters
  Back-Up Battery	Built-In
